Antenna: Internal 10 Hz GPS/GNSS
Dimensions: 17.19 x 10.08 x 3.82"; Wt: 10.25 lb.
Display: 16" Multi-Touch color LCD with keypad control
Interface: Ehternet; NMEA 2000, WiFi, Bluetooth
Mapping: Pre-loaded C-Map Contour+ inl& & offshore maps for US/Canada
Other Functions: Optional AIS, TripIntel technology, Auto routing, engine monitoring, SonicHub, Autopilot control
Radar: Accepts Navico Broadband, pulse, or HALO Radars
Resolution: 1920 x 1280 pixels
Sounder: Built-in CHIRP/DownScan/SideScan Sonar (Transducer dependent). Optional ForwardScan sonar.
Waypoints/Routes: 16GB internal storage, 500 routes with 100 max route points, 50 tracks with upto 12,000 track points
Features:
- iMX 8 Integrated six-core processor for superior performance
- 9-inch SolarMAX IPS display with ultra-wide viewing angles; viewable through Polarized sunglasses
- Switch seamlessly between touchscreen and keypad control
- Built in high-performance echosounder with 1kW CHIRP, Built-in GPS receiver and wireless connectivity
- Control Simrad sonar, radar, autopilot, and other accessories
- Industry-standard connectivity to engines, sound system, and more
- Choose low-profile flush mounting or convenient bracket mounting
- Download the Simrad App and connect with smartphones, tablets, and internet hotspots
- Preloaded C-MAP US Enhanced charts provide detailed mapping with 1-foot contours, easy routing and C-MAP Reveal data in Florida
- Limited 2 Year Warranty
In the box:
- NSS16 Evo3S
- Suncover
- Powercord
- Gimbal bracket
- Dash mount kit
- Documentation
